Monoblock Refrigeration Unit NZ manufacturer and supplier-Glen refrigeration is a leading condensing unit manufacturer and monoblock refrigeration unit manufacturer in China.

The monoblock refrigeration unit is a packaged refrigeration unit, combines condensing unit and evaporator unit into a compact refrigeration system. According to the difference installation place, it can be divided into wall mounted refrigeration unit and ceiling mounted refrigeration unit. They are all monoblock cold room refrigeration unit.

The split refrigeration system is composed of two parts, one is condensing unit (also called cold room outdoor unit). It is installed outside of the cold room or freezer room. The other part is the evaporator unit (also called cold room indoor unit). It is installed inside of the cold room. The condensing unit and evaporator unit are separate and customer need to connect them by piping when installation.

The cold room outdoor unit is composed of the refrigeration compressor, condenser, fan motor, oil separator, receiver, filter dryer, sight-glass, solenoid valve, accumulator, high and low pressure switch, high and low pressure gauge, stop valve, water proof housing, electric parts and so on.

The evaporator is another part of the split refrigeration system for cold room and freezer room. If choose slit refrigeration system, customer need to connect the outdoor unit and indoor unit by piping, then vacuum, charge in the refrigerant on site.

The monoblock refrigeration system, on the contrary, integrated the condensing unit and evaporator unit together. No need to connect by piping, no need to vacuum, no need to charge in refrigerant on site. It is pre-assembled, pre-tested, pre-charged in the factory and ready to use when customer buys monoblock condensing unit.

  • Pre-charged with Refrigerant

The cold room monoblock is a pre-tested and pre-chared refrigerant in the factory, our customer don’t need to charge the refrigerant on site anymore.

  • Quick and easy installation

The monoblock cooling unit is pre-assembled, the condensing unit and evaporator unit are in the same construction. Customers don’t need to connect the outdoor unit and indoor unit by piping. Just plug in and ready to use.

  • High efficiency and energy-saving

Glen refrigeration’s monoblock refrigeration unit nz, features Sanyo variable speed refrigeration compressor, the compressor frequency and speed can be adjusted automatically according to different refrigeration load to achieve high efficiency and save more energy.

  • Reverse cycle hot gas defrosting

The refrigeration monoblock adopts reverse cycle hot gas defrost. Compared with electric defrost, hot gas defrosting can melt the frost or ice more efficiently. Short defrost period, small temperature fluctuation.

  • MT and LT cold rooms possible

Glen refrigeration monoblock refrigeration unit nz is designed for MT and LT cold rooms. Customers can adjust the cold room temperature on the control panel.

  • Natural refrigerant R290

Except the R404A R449A monoblock freezer unit, Glen refrigeration also offers R290 monoblock cold room refrigeration unit to reduce GWP emission.

The wall mounted refrigeration unit is one kind of monoblock refrigeration unit, mounted on the wall panel of the cold room. Glen refrigeration offers inverter wall mounted refrigeration unit from 1 HP to 4 HP for cold room and freezer room.

  • Model: GL-BYTCN10EL
  • Refrigerant: R404A,R449A
  • Power supply: 220V~240V/50Hz or 220V/60Hz
  • Cooling Capacity: 1 HP
  • Defrost: Hot gas defrosting
  • Application: MT and LT
  • Model: GL-BYTCN20EL
  • Refrigerant: R404A,R449A
  • Power supply: 220V~240V/50Hz or 220V/60Hz
  • Cooling Capacity: 2 HP
  • Defrost: Hot gas defrosting
  • Application: MT and LT
  • Model: GL-BYTCN30EL
  • Refrigerant: R404A,R449A
  • Power supply: 220V~240V/50Hz or 220V/60Hz
  • Cooling Capacity: 3 HP
  • Defrost: Hot gas defrosting
  • Application: MT and LT
  • Model: GL-BYTCN40EL
  • Refrigerant: R404A,R449A
  • Power supply: 220V~240V/50Hz or 220V/60Hz
  • Cooling Capacity: 4 HP
  • Defrost: Hot gas defrosting
  • Application: MT and LT

Ceiling mounted refrigeration unit for cold room and freezer room, mounted on the roof panel of the cold room. Glen refrigeration offers inverter ceiling mounted refrigeration unit from 1 HP to 3 HP for cold room and freezer room.

  • Model: GL-BYTDN10EL
  • Refrigerant: R404A,R449A
  • Power supply: 220V~240V/50Hz or 220V/60Hz
  • Cooling Capacity: 1 HP
  • Defrost: Hot gas defrosting
  • Application: MT and LT
  • Model: GL-BYTDN20EL
  • Refrigerant: R404A,R449A
  • Power supply: 220V~240V/50Hz or 220V/60Hz
  • Cooling Capacity: 2 HP
  • Defrost: Hot gas defrosting
  • Application: MT and LT
  • Model: GL-BYTDN30EL
  • Refrigerant: R404A,R449A
  • Power supply: 220V~240V/50Hz or 220V/60Hz
  • Cooling Capacity: 3 HP
  • Defrost: Hot gas defrosting
  • Application: MT and LT

The wall mounted refrigeration unit is mounted on the wall panel of the cold room or freezer room.

First step: Prepare a opening with suitable dimensions on the wall panel. (See the picture below).This is best done using an angle grinder (a jigsaw may also be used).

Please see the opening size dimension below:

Modelab
GL-BYTCN10EL 440mm 390mm
GL-BYTCN20EL620mm450mm
GL-BYTCN30EL790mm450mm
GL-BYTCN40EL880mm460mm

Second step: Place the evaporator side of the unit smoothly from the open window and remain stable.

Third step: There are two hangers above the monoblock condensing unit. Drill holes in the hangers from the outside to the inside with an electric drill. After the holes are made, install them from the inside to the outside with mushroom head screw bolt and bolt them to the outside of the cold storage.

The ceiling mounted refrigeration unit is mounted on the top panel of the cold room.

First step: Prepare a opening with suitable dimensions on the top panel. (See the picture below).This is best done using an angle grinder (a jigsaw may also be used).

Please see the opening size dimension below:

ModelL2W2
GL-BYTDN10EL870mm460mm
GL-BYTDN20EL1110mm510mm
GL-BYTDN30EL1280mm540mm

Second step: Place the monoblock unit in place on the pre-drilled top panel, and fix the unit to the top plate with screws.

Third step: Lift the top panel with the monoblock unit together and place it on the  left and right lifting platforms. At the same time, shake the handle to raise the lifting platform. After it reaches a sufficient height, push the top plate up the wall panel and adjust the position of the top plate.

The monoblock refrigeration unit is designed for MT and LT cold rooms. The temperature range is HBP(+2℃ to +8℃) MBP(-5℃ to +5℃) and LBP (-15℃ to -18℃).

Note: -8.5°C is actual temperature.  -12.0°C is setting temperature.

Under this interface, press the “Up arrow” key one time, the setting temperature increase 1°C.

Under this interface,  press the “Down arrow” key one time, the setting temperature decrease 1°C.
