R404A Compressor for Commercial Refrigeration

Sanyo R404a LBP MBP compressor
High reliability
High efficiency
Medium and low temperature

Your Best R404A Compressor Manufacturer and Supplier

Sanyo, is a leading manufacturer of rotary compressor for air conditioning and commercial refrigeration in the world. Sanyo took the lead in introducing rotary refrigeration compressor to Japanese market, then gradually expanded to the world. More than 30 years, Sanyo designers and engineers carry on that tradition with industry-leading technologies for commercial refrigeration.

Glen Refrigeration has proudly served the commercial refrigeration market with Sanyo rotary refrigeration compressor. We are passionate about helping our customers keep ahead in commercial refrigeration industry with Sanyo refrigeration compressors, horizontal condensing unit, outdoor condensing unit and monoblock refrigeration unit.

R404a Refrigeration Compressor Product Range

220V~240V/50HZ Single Phase

Horizontal Refrigeration Compressor

380V/50HZ Three Phase

Horizontal Refrigeration Compressor

220V/60HZ Single Phase

Horizontal Refrigeration Compressor

220V~240V/50HZ Single Phase

Vertical Refrigeration Compressor

380V/50HZ Three Phase

Vertical Refrigeration Compressor

220V/60HZ Single Phase

Vertical Refrigeration Compressor

Features and Benefits of Sanyo R404A Compressor

High Reliability

Sanyo refrigeration compressor’s high reliability is more than a pledge. It’s most important deliverable. It is famous for its high reliability and obtains high market recognition over these years.

High efficiency

Sanyo rotary refrigeration compressor has been leading the way in energy efficiency for decades. Glen refrigeration offer optimization condensing units to help our partners lower energy use and costs.

Low Vibration

The unique rectification and noise reduction technology of the pump body in the rotary compressor ensure the sensory comfort of the vibration and noise transmitted from the refrigeration compressor.

Wide Evaporating Temperature

The lowest evaporating temperature is -45 ℃, minimum -35 ℃ freezing temperature. It is a medium temperature compressor and also a low temperature compressor for commercial refrigeration.

Liquid Injection Technology

Sanyo refrigeration rotary compressor adopts liquid injection technology, solving the problem of high discharge temperature under high compression ration condition. or low evaporating temperature condition.

Horizontal R404A Refrigeration Compressor (220V~240V/50HZ)

Glen Refrigeration offers 220V~240V/50HZ R404A refrigeration compressor, horizontal design, featuring low height and compact size. They are widely used in horizontal condensing unit for upright display fridge and freezer, meat display cabinet, commercial ice cream display freezer, self-contained refrigerated display cases, and other commercial refrigeration equipment.

Product: R404A Refrigeration Compressor
Power Supply: 220V~240V/50HZ, Single phase
Cooling capacity: 3/4 HP to 3 HP
Application: MBP and LBP

3/4 HP refrigeration compressor

Model: C-RHN75E4A
Refrigerant: R404A
Compressor displacement: 13.3 cc
Power supply: 220V~240V/50HZ
Rated cooling capacity: 3000 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3/4 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 179mm
Available Refrigerant: R448A, R449A

1 HP refrigeration compressor

Model: C-RHV161L4AAL
Refrigerant: R404A
Compressor displacement: 16.1 cc
Power supply: 220V~240V/50HZ
Rated cooling capacity: 3700 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 1 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 179mm
Available Refrigerant: R448A, R449A

1.5 HP refrigeration compressor

Model: C-RHN110E4A
Refrigerant: R404A
Compressor displacement: 22.0 cc
Power supply: 220V~240V/50HZ
Rated cooling capacity:5200 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 1.5 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 179mm
Available Refrigerant: R448A, R449A

2 HP refrigeration compressor

Model: C-3RH322L4AAL
Refrigerant: R404A
Compressor displacement: 32.2 cc
Power supply: 220V~240V/50HZ
Rated cooling capacity:6800 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 222mm
Available Refrigerant: R448A, R449A

2.5 HP refrigeration compressor

Model: C-3RHV359L4AAL
Refrigerant: R404A
Compressor displacement: 35.9 cc
Power supply: 220V~240V/50HZ
Rated cooling capacity:8000 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2.5 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 222mm
Available Refrigerant: R448A, R449A

3 HP refrigeration compressor

Model: C-3RH463L4AAL
Refrigerant: R404A
Compressor displacement: 46.3cc
Power supply: 220V~240V/50HZ
Rated cooling capacity:10200 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 222mm
Available Refrigerant: R448A, R449A

Horizontal R404A Refrigeration Compressor (380V/50HZ)

Glen Refrigeration offers R404A, 380V/50HZ, 3 Phase Sanyo rotary refrigeration compressor for commercial refrigeration, featuring wide evaporating temperature range -45℃～-5℃. It is a MBP compressor and also a LBP compressor, widely used in medium temperature refrigeration and also low temperature refrigeration applications.

Product: R404A Refrigeration Compressor
Power Supply: 380V/50HZ, 3 Phase
Cooling capacity: 2 HP to 3 HP
Application: MBP and LBP

2 HP refrigeration compressor

Model: C-3RN153L8A
Refrigerant: R404A
Compressor displacement: 32.2 cc
Power supply: 380V/50HZ, 3PH
Rated cooling capacity:6550 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 222mm
Available Refrigerant: R448A, R449A

3 HP refrigeration compressor

Model: C-RHN223L8A
Refrigerant: R404A
Compressor displacement: 46.3cc
Power supply: 380V/50HZ, 3PH
Rated cooling capacity:9500 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 222mm
Available Refrigerant: R448A, R449A

Horizontal R404A Refrigeration Compressor (220V/60HZ)

R404A refrigeration compressors with power supply 220V/60HZ are specially design for USA, Canada, Korea, Saudi Arabia and other 220V/60HZ power supply market. Glen Refrigeration offers high reliability R404A 220V/60HZ commercial refrigeration compressors, horizontal design, low height and compact size.

Product: R404A Refrigeration Compressor
Power Supply: 220V/60HZ
Cooling capacity: 3/4 HP to 3 HP
Application: MBP and LBP

3/4 HP refrigeration compressor

Model: C-RHN75E6A
Refrigerant: R404A
Compressor displacement: 13.3 cc
Power supply: 220V/60HZ
Rated cooling capacity: 3500 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3/4 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 179mm
Available Refrigerant: R448A, R449A

1 HP refrigeration compressor

Model: C-RHC161L4AAL
Refrigerant: R404A
Compressor displacement: 16.1 cc
Power supply: 220V/60HZ
Rated cooling capacity: 4400 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 1 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 179mm
Available Refrigerant: R448A, R449A

1.5 HP refrigeration compressor

Model: C-RHN110E6A
Refrigerant: R404A
Compressor displacement: 22.0 cc
Power supply: 220V/60HZ
Rated cooling capacity:6300 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 1.5 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 179mm
Available Refrigerant: R448A, R449A

2 HP refrigeration compressor

Model: C-3RHC322L4AAL
Refrigerant: R404A
Compressor displacement: 32.2 cc
Power supply: 220V/60HZ
Rated cooling capacity:8160 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 222mm
Available Refrigerant: R448A, R449A

2.5 HP refrigeration compressor

Model: C-3RHC359L4AAL
Refrigerant: R404A
Compressor displacement: 35.9 cc
Power supply: 220V/60HZ
Rated cooling capacity:9600 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2.5 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 222mm
Available Refrigerant: R448A, R449A

3 HP refrigeration compressor

Model: C-3RHC463L4AAL
Refrigerant: R404A
Compressor displacement: 46.3cc
Power supply: 220V/60HZ
Rated cooling capacity:12240 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 222mm
Available Refrigerant: R448A, R449A

Vertical R404A Refrigeration Compressor (220V~240V/50HZ)

Glen Refrigeration offers Sanyo 220V~240V/50HZ commercial refrigerator compressor, vertical installation. They are widely used in outdoor condensing unit, remote condensing unit for cold room, freezer room, walk in cooler, walk in freezer.

Product: R404A Refrigeration Compressor
Power Supply: 220V~240V/50HZ
Cooling capacity: 3/4 HP to 3 HP
Application: MBP and LBP

3/4 HP refrigeration compressor

Model: C-R133L4AL
Refrigerant: R404A
Compressor displacement: 13.3 cc
Power supply: 220V~240V/50HZ
Rated cooling capacity: 2900 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3/4 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 319.1 mm
Available Refrigerant: R448A, R449A

1.5 HP refrigeration compressor

Model: C-R220L4AL
Refrigerant: R404A
Compressor displacement: 22.0 cc
Power supply: 220V~240V/50HZ
Rated cooling capacity:5000 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 1.5 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 319.1 mm
Available Refrigerant: R448A, R449A

2 HP refrigeration compressor

Model: C-3R322L4AAL
Refrigerant: R404A
Compressor displacement: 32.2 cc
Power supply: 220V~240V/50HZ
Rated cooling capacity:6800 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 392.8 mm
Available Refrigerant: R448A, R449A

3 HP refrigeration compressor

Model: C-3R463L4AAL
Refrigerant: R404A
Compressor displacement: 46.3cc
Power supply: 220V~240V/50HZ
Rated cooling capacity:10300 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 392.8mm
Available Refrigerant: R448A, R449A

Vertical R404A Refrigeration Compressor (380V/50HZ)

380V/50HZ, 3 Phase R404A commercial refrigerator compressor for MBP and LBP. Glen refrigeration offers high reliable Sanyo CRSS compressor for outdoor condensing unit and remote condensing unit for cold room, freezer room, walk in cooler, walk in freezer and other commercial refrigeration equipment.

Product: R404A refrigeration compressor
Power Supply: 380V/50HZ, 3 Phase
Cooling capacity: 1 HP to 3 HP
Application: MBP and LBP

3/4 HP refrigeration compressor

Model: C-RN83L8A
Refrigerant: R404A
Compressor displacement: 16.1 cc
Power supply: 380V/50HZ 3PH
Rated cooling capacity:3400 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 1 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 319.1 mm
Available Refrigerant: R448A, R449A

1.5 HP refrigeration compressor

Model: C-RN113L8A
Refrigerant: R404A
Compressor displacement: 22.0 cc
Power supply: 380V/50HZ 3PH
Rated cooling capacity:4600 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 1.5 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 319.1 mm
Available Refrigerant: R448A, R449A

2 HP refrigeration compressor

Model: C-3RP322L4AAL
Refrigerant: R404A
Compressor displacement: 32.2 cc
Power supply: 380V/50HZ 3PH
Rated cooling capacity:6500 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 392.8 mm
Available Refrigerant: R448A, R449A

2.5 HP refrigeration compressor

Model: C-3RP359L4AAL
Refrigerant: R404A
Compressor displacement: 35.9 cc
Power supply: 380V/50HZ 3PH
Rated cooling capacity:7500 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2.5 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 392.8 mm
Available Refrigerant: R448A, R449A

3 HP refrigeration compressor

Model: C-3RP463L4AAL
Refrigerant: R404A
Compressor displacement: 46.3cc
Power supply: 380V/50HZ 3PH
Rated cooling capacity:10200 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 392.8mm
Available Refrigerant: R448A, R449A

Vertical R404A Refrigeration Compressor (220V/60HZ)

220V/60HZ commercial refrigeration compressors are suitable for USA, Canada, Mexico, Korea, Saudi, Arabia, Peru, Philippines & some Caribbean island nations. Glen Refrigeration offers 220V/60HZ Sanyo CRSS compressor, MBP & LBP compressor for outdoor condensing units, air cooled condensing units for cold room, freezer room and other commercial refrigeration equipment.

Product: R404A refrigeration compressor
Power Supply: 380V/50HZ, 3 Phase
Cooling capacity: 3/4 HP to 3 HP
Application: MBP and LBP

3/4 HP refrigeration compressor

Model: C-RC133L4AAL
Refrigerant: R404A
Compressor displacement: 13.3 cc
Power supply: 220V/60HZ
Rated cooling capacity: 3500 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3/4 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 319.1 mm
Available Refrigerant: R448A, R449A

1 HP refrigeration compressor

Model: C-RC161L4AAL
Refrigerant: R404A
Compressor displacement: 16.1 cc
Power supply: 220V/60HZ
Rated cooling capacity:4500 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 1 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 319.1 mm
Available Refrigerant: R448A, R449A

1.5 HP refrigeration compressor

Model: C-RC220L4AAL
Refrigerant: R404A
Compressor displacement: 22.0 cc
Power supply: 220V/60HZ
Rated cooling capacity:6000 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 1.5 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 319.1 mm
Available Refrigerant: R448A, R449A

2 HP refrigeration compressor

Model: C-3RC322L4AAL
Refrigerant: R404A
Compressor displacement: 32.2 cc
Power supply: 220V/60HZ
Rated cooling capacity:8200 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 392.8 mm
Available Refrigerant: R448A, R449A

2.5 HP refrigeration compressor

Model: C-3RC359L4AAL
Refrigerant: R404A
Compressor displacement: 35.9 cc
Power supply: 220V/60HZ
Rated cooling capacity:9500 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 2.5 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 392.8 mm
Available Refrigerant: R448A, R449A

3 HP refrigeration compressor

Model: C-3RC463L4AAL
Refrigerant: R404A
Compressor displacement: 46.3cc
Power supply: 220V/60HZ
Rated cooling capacity:12000 Btu/h
Test evaporating temp: -23.3℃
Horsepower: 3 HP
Evaporating temp.: -45℃～-5℃
Condensing temp.: +30℃～+60℃
Height: 392.8mm
Available Refrigerant: R448A, R449A

R404A Compressor Accessories

Spring and Rubber Mounting Accessories

Sanyo specially designed the spring and rubber mounting accessories for the horizontal rotary refrigeration compressor, reducing the vibration transmitted through the condensing unit base plate or tubes to generate noise.

Electric Box

The electric box is including the start capacitor, run capacitor, and replay. The start capacitor is used to give a motor an extra electrical push to start.

Crankshaft heater

Keep the compressor oil at a certain temperature, heating the oil and help the refrigeration condensing unit to start normally in low ambient temperature.

Horizontal Refrigeration Rotary Compressor For Horizontal Condensing Unit

The horizontal rotary refrigeration compressor, featuring low height and compact size, mainly used in horizontal air cooled condensing unit, water-cooled condensing unit for commercial refrigeration and transport refrigeration and so on.

Higher performance and high efficiency.
Wide evaporating temperature from -45℃～-5℃
Low height and compact size, space saving for showcase
Low noise and low vibration
Liquid injection technology
Power supply 220V~240V/50HZ, 220V/60HZ 380V/50HZ 3PH
Sanyo brand, high reliability, quality assurance.

Vertical Refrigeration Rotary Compressor for Outdoor Condensing Unit

The vertical refrigeration rotary compressor, mainly used in outdoor condensing unit for cold room, freezer room, walk in cooler and walk in freezer.

Higher performance and high efficiency.
Wide evaporating temperature from -45℃～-5℃
Easy installation for remote condensing unit
Liquid injection technology
Power supply 220V~240V/50HZ, 220V/60HZ 380V/50HZ 3PH
Sanyo brand, high reliability, quality assurance.

info@greehvacr.com
